4308.00 (Inc VAT)
Settings To Optimize Your Results Heliarc Has The Functionality To Achieve Excellent Results.
AC & DC Pulse, Extended AC Frequency & Balance Controls, Ability To Store 60 Programs And The Ability To Switch Between Two Amperage Levels While Welding Are Just A Few Of The Features.
AC & DC Pulse - Used To Regulate Heat Input, Particularly Advantageous On Thin Materials. Using Pulse, Increases Arc Stability & Puddle Control For Faster Welding Speeds With Less Plate Deformation.
Varying The Pulse Frequency Effects Heat Input Creating A Rippling Effect In The Weld Bead.
Pulse Frequency, Together With Weld Speed, Determines Size & Distance Between Surface Ripples Desired For A High Quality Aesthetic Appearance .
Using More Than100hz Gives A Smooth Weld (No Ripples) And Improves Arc Stability At Low Amps.
Features
- High quality AC/DC TIG & MMA welding, the new Heliarc power sources have everything you need for advanced AC/DC TIG welding of aluminium, aluminium alloys, magnesium alloys, stainless steel, mild steel and copper alloys. Heliarc weld stick electrodes, even difficult to start ‘Cellulosic’ AWS 60XX.
- Excellent Arc control - Stable arc characteristics and settings provide excellent arc control and fast welding speed
- Electrode preheating - Excellent arc starts, maintains tungsten shape and extended life.
- AC or DC Pulsed TIG welding - Easy control of heat input and the weld pool. enhanced aesthetic weld bead appearance.
- Dual TIG function - Switch between two weld current levels while welding via torch switch. Allows operator to manually control weld puddle fluidity.
- Superior Stick (SMAW) performance - Even with 60XX electrodes
- Liftarc Mode even on AC - Ideal for applications where HF (High Frequency) is not permitted.
- Inverter / microprocessor technology - Highly efficient with low input power requirements. Precise arc control coupled with low weight & size
- AC Pulsing 0.2-2Hz - Ideal for thin gauge aluminium
