SKU: X5220200000
1941.60 (Inc VAT)
BENEFITS
• Side-loading wire feeder allows easy wire spool changes
• Clear 2-knob control panel with a digital parameter display
• Designed for MIG, MMA, and gouging processes
• 4-wheel wire feed mechanism with integrated lighting guarantees a steady and reliable wire feed
• Compact-sized and lightweight wire feeder enables excellent mobility
• Impact-resistant, durable, double-walled cabinet for heavy-duty environments
• USB port connectivity for convenient system software updates
Product code - X5220200000
Wire feed mechanism - 4-roll, single-motor
Wire feed speed - 0.5 ... 25 m/min
Gun connection - Euro
Wire spool weight, max. - 5.0 kg
Wire spool diameter, max. - 200 mm
Filler wires Fe - 0.8 ... 1.6 mm Ss 0.8 ... 1.6 mm
Mc/Fc - 0.8 ... 2.0 mm Al 0.8 ... 2.4 mm
Diameter of feed rolls - 32 mm
Operating temperature range - -20...+40 °C
External dimensions LxWxH - 565 x 218 x 339 mm
Weight (no accessories) - 9.7 kg
Degree of protection - IP23S
EMC class - A
Storage temperature range - -40...+60 °C
Shielding gas pressure (max) - 0.5 MPa
Welding current, 60 % - 500 A
Welding current, 100 % - 430 A
Weight
9.7
Height
34
Width
22
Depth
57
